Page 64 - การดาดผิว

5 - 7

ี
่
ตารางท 5-3 AIRCRAFT DATA SHEET - REAR AREA AIRFORCE AIRFIELDS
MAX. DESIGN TIRE CONTACT DISIGN CURVE FIGURE RECOMMENDED MINIMUM THICKNESS OF PAVEMENT AND BASE (In.)
AIRCRAFT TAKE OFF LOAD PRESS AREA TO BE USED 80 CBR BASE 100 CBR BASE

WT. Kips WT. Kips P.S.I. SQ.In. EMERG. MIN. FULL PAVEMENT BASE PAVEMENT BASE
BOMBER EMERG. MIN. FULL EMERG. MIN. FULL EMERG. MIN. FULL EMERG. MIN. FULL
B-47E 230.0 129 230 280 5-25 5-26 5-27 2 2 2 6 6 6 2 2 2 6 6 6

B-52H 488.0 268.5 285 236 5-25 5-26 5-27 3.5 4.5 5.5 6 6 6 2.5 3.5 4.5 6 6 6
B-57B 57.0 26.9 150 180 5-7 5-8 5-9 2.5 3 3.5 6 6 6 2 2.5 3 6 6 6
B-66B 83 35.8 128 279.0 5-4 5-5 5-6 2 2 2 6 6 6 2 2 2 6 6 6

CARGO
C-5A 769 199.8 115 190 5-28 5-29 5-30 2 2 2 6 6 6 2 2 2 6 6 6
C-7A 28.5 12.8 43 - - - - DST DST DST 6 6 6 DST DST DST 6 6 6
C-47D 33 15.8 60 263 5-4 5-5 5-6 DST DST 1.5 6 6 6 DST DST DST 6 6 6
C-54G 73 34.1 77 222 5-10 5-11 5-12 DST 1.5 2 6 6 6 DST DST DST 6 6 6

C-97G(KC) 187 88.9 180 247 5-19 5-20 5-21 2 2.5 3 6 6 6 1.5 2 2 6 6 6
C-118A 129.4 62.8 124 252 5-10 5-11 5-12 2 3 3.5 6 6 6 1.5 2.5 2.5 6 6 6
C-119G 72.7 32.7 80 205 5-10 5-11 5-12 1.5 1.5 1.5 6 6 6 DST DST DST 6 6 6
C-121G 145 69.4 130 266 5-19 5-20 5-21 1.5 2 2.5 6 6 6 DST 1.5 1.5 6 6 6

C-123B 58.8 24.7 90 274 5-4 5-5 5-6 DST 1.5 1.5 6 6 6 DST DST 2 6 6 6
C-124C 216 101 79 640.0 5-16 5-17 5-18 2.5 2.5 3 6 6 6 1.5 2 2.5 6 6 6
C-130E 175 83.8 95 440 5-13 5-14 5-15 2 2.5 3 6 6 6 1.5 2 2.5 6 6 6
