ผนวก ข.

่
ตารางที 5 - 2 Characteristics of Certain Air Force Aircraft.
Aircraft Overall Dimensions,(M) weight ( tons ) Main gear tires takeoff (hard surface)

Designation Maximum Contact Sea level O wind,m
lenght width height Basic takeoff Gear type PSI area (sq.cm.) ground run clear,15m

F-111 A 22.6 19.2 5.2 21.0 38.5 Single-trcycle (TN) 150 1,574 - -

F-4C 17.7 11.7 5.0 14.3 29.6 Single-trcycle (TN) 255 658 1,281 1,553
F-5A 14.4 8.7 4.0 4.3 10.0 Single-trcycle (SN) 210 265 2,058 2,485
C-47D 19.6 29.0 5.2 9.1 16.5 Single-conventional 60 1,697 885 1,555
C-54G 28.6 35.8 8.4 19.7 36.5 Twin-trcycle (SN) 77 1,432 635 1,197
C-97G (KC) 33.6 43.0 11.7 41.6 93.5 Twin-Trcycle (TN) 180 1,594 2,561 3,232
C-118A 32.6 35.8 8.9 29.6 64.7 Twin-Trcycle (SN) 124 1,626 1,769 2,287
C-119G 26.4 33.3 8.0 20.6 36.4 Twin-Trcycle (SN) 80 1,323 970 1,668 ข-1
C-121G 35.4 37.5 7.6 37.6 72.5 Twin-Trcycle (TN) 130 1,716 1,220 1,921
C-123B 23.2 33.5 10.5 15.6 29.4 Single-Tricycle 90 1,768 924 1,479
C-124G 39.6 53.1 14.8 51.5 108.2 Twin-Trcycle (TN) 79 4,129 1,683 2,250
C-130F 29.8 40.4 11.7 35.8 87.5 Single Tandem Tricycle 95 2,839 1,098 1,609
HC-130H 34.1 40.4 11.7 40.9 87.5 Single Tandem Tricycle 115 2,349 967 1,418
C-131E 24.1 32.1 8.6 16.7 30.3 Twin-Trcycle (TN) 90 1,052 1,092 1,571
C-133B 48.0 54.8 14.9 61.8 150.0 Twin-Tandem Tricycle 98 2,387 1,537 1,720
C-135A 41.0 40.0 12.7 50.1 138.8 Twin-Tandem Tricycle 143 1,484 2,647 3,132
KC-135A 41.5 40.0 11.7 49.6 150.4 Twin-Tandem Tricycle 155 1,484 2,988 3,763
C-140A 18.4 16.4 6.3 11.3 20.3 Twin-Tandem Tricycle 205 227 1,119 1,571
C-141A 44.2 49.4 12.0 68.2 158.3 Twin-Tandem Tricycle 180 1,342 1,189 1,473
C-5A 75.0 67.9 19.8 159.3 384.5 Dual Triangular Tandem 115 1,871 1,979 2,616
C-7A 22.1 29.1 9.7 9.3 14.3 Twin-Trcycle (TN) 39 968 191 305
